Environmental solution-OIL


“MIST CATCH” Filter Oil Mist Collector
Option for OMC-F Series


Option parts

Option for OMC-F Series

Option list

Part name Part number
For OMC-F105 For OMC-F110 For OMC-F120
A Primary filter
(Common to OMC-N1)
OMC-F105-F10 OMC-F110-F10 OMC-F120-F10
B Secondary filter
OMC-F105-F20 OMC-F110-F20 OMC-F120-F20
C Tertiary filter OMC-F105-F30 OMC-F110-F30 OMC-F120-F30
D-1 After filter
(Common to OMC-N1)
OMC-F105-F40-1 OMC-F110-F40-1 OMC-F120-F40-1
D-2 After filter OMC-F105-F40-2 OMC-F110-F40-2 OMC-F120-F40-2
E Replacement filter for After filter
(Common to OMC-N2) ※
OMC-AF-335L OMC-AF-500L
F Chip separator OMC-F105A-CS OMC-F110A-CS OMC-F120A-CS
G Replacement filter for Chip separator OMC-F105-CS-F00 OMC-F110-CS-F00 OMC-F120-CS-F00

※ This is a replacement filter for After Filter OMC-F**-F40-2 and not applicable for OMC-F**-F40-1.

<Difference between After Filters D-1 and D-2>

  • D-1 (OMC-F**-F40-1) : The filter material is not detachable. The whole unit has to be replaced. Secured by band.
  • D-2 (OMC-F**-F40-2): The filter material is replaceable. Secured by 3 screws.
