<Type BEC> Microcomputer-controlled, Outdoor use

Highly efficient cooling to save energy! CFC-free compact cooler with plenty of functions

【Specifications】

[OCE-100BEC-AW]　Cooling capacity （50Hz／60Hz）　100　W

[OCE-200BEC-AW]　Cooling capacity （50Hz／60Hz）　210　W



<Type FSCJ> Microcomputer-controlled, drain free

The integrated evaporator has achieved drain free eliminating troublesome drainage treatment. ／Fan-cooled (hot side)：Cool air agitation (cold side)

【Specifications】

[OCE-100FSCＪ-A1・A2]　Cooling capacity （50Hz／60Hz）　90／100　W

[OCE-200FSCＪ-A1・A2]　Cooling capacity （50Hz／60Hz）　180／200　W



<Type FSC> Microcomputer-controlled

Small and light weight body! ／Fan-cooled (hot side)：Cool air agitation (cold side)

【Specifications】

[OCE-100FSC-A1・A2]　Cooling capacity （50Hz／60Hz）　90／100　W

[OCE-200FSC-A1・A2]　Cooling capacity （50Hz／60Hz）　180／200　W



<Type F> Without power supply

Concurrent power input of AC and DC. Resistant to dust and mist.
／Fan-cooled (hot side)：Cool air agitation (cold side)

【Specifications】

[OCE-40F-A1・A2]　　Cooling capacity （50Hz／60Hz）　38／40　W

[OCE-80F-A1・A2]　　Cooling capacity （50Hz／60Hz）　76／80　W

[OCE-160F-A1・A2]　Cooling capacity （50Hz／60Hz）　155／160　W

<Type FP> For built-in use　

Directly-cooled plate surface absorbs heats from an object without heat losses.
／Fan-cooled (hot side)：Plate cooling (cold side)

【Specifications】

[OCE-F15P-D12]　Cooling capacity　20W　・　Heating capacity　60W

[OCE-F40P-D24]　Cooling capacity　55W　・　Heating capacity　160W

[OCE-F80P-D24]　Cooling capacity　110W　・　Heating capacity　320W

<Type FF> For built-in use　

DC power input. Cools and agitates air with the fan on cooling side.
／Fan-cooled (hot side)：Cool air agitation (cold side)

【Specifications】

[OCE-F15F-D12]　Cooling capacity　15W　・　Heating capacity　60W

[OCE-F40F-D24]　Cooling capacity　40W　・　Heating capacity　160W

[OCE-F80F-D24]　Cooling capacity　80W　・　Heating capacity　300W

　　　　　　　　　　　　　　 [OCE-F120F-D24]　Cooling capacity　120W　・　Heating capacity　450W

<Type FL> For built-in use

DC power input. Cools fluids to meet various needs.
／Fan-cooled (hot side)：Fluid cooling(cold side)

【Specifications】

[OCE-F80LA-D24]　Cooling capacity　95W　・　Heating capacity　300W

[OCE-F80LT-D24]　Cooling capacity　90W　・　Heating capacity　300W

[OCE-F160LA-D24]　Cooling capacity　220W　・　Heating capacity　620W

[OCE-F160LT-D24]　Cooling capacity　190W　・　Heating capacity　620W

[OCE-F240LA-D24]　Cooling capacity　320W　・　Heating capacity　930W

[OCE-F240LT-D24]　Cooling capacity　280W　・　Heating capacity　930W

<Type LP> For built-in use

Directly-cooled plate surface absorbs heats from an object without heat losses.
／Water-cooled (hot side)：Plate cooling (cold side)

【Specifications】

[OCE-L15P-D12]　Cooling capacity　25W　・　Heating capacity　70W

[OCE-L40P-D24]　Cooling capacity　75W　・　Heating capacity　190W

[OCE-L80P-D24]　Cooling capacity　140W　・　Heating capacity　380W

<Type LF> For built-in use

DC power input. Cools and agitates air with the fan on cooling side.
／Water-cooled (hot side)：Cool air agitation (cold side)

【Specifications】

[OCE-L15F-D12]　Cooling capacity　20W　・　Heating capacity　60W

[OCE-L40F-D24]　Cooling capacity　60W　・　Heating capacity　190W

[OCE-L80F-D24]　Cooling capacity　125W　・　Heating capacity　370W

<Type LL> For built-in use

DC power input. Cools fluids to meet various needs.
／Water-cooled (hot side)：Fluid cooling (cold side)

【Specifications】

[OCE-L80LA-D24]　Cooling capacity　140W　・　Heating capacity　240W

[OCE-L80LT-D24]　Cooling capacity　125W　・　Heating capacity　240W

[OCE-L160LA-D24]　Cooling capacity　300W　・　Heating capacity　480W

　　　　　　　　　　　　　　 [OCE-L160LT-D24]　Cooling capacity　240W　・　Heating capacity　480W

<Simplified type> Without power supply　

Designed specially for BOXCOOL, PID ON/.OFF control with auto-tuning function

【Specifications】

[OCE-TC91-8Y1-1C]　Contact output ：240VAC/20A (resistance load) 24-VAC/1.2A (induction load)

[OCE-TC91-8P3-1C]　11V ±1VDC (at load resistance 1.5kΩ), 30mA or less load current

<Inversion type> With power supply　

Thermal controller specially for Peltier modules, PID control with auto-tuning function

【Specifications】

[OCE-TCR12075WL]Peltier control output rating：±12VDC 6.3A Fan motor output rating：12VDC 0.8A

[OCE-TCR24150WL]Peltier control output rating：±24VDC 6.3A Fan motor output rating：24VDC 0.8A

[OCE-TCR24300WL]Peltier control output rating：±24VDC 14.0A Fan motor output rating：24VDC 1.4A

[OCE-TCR24600WL]Peltier control output rating：±24VDC 27.0A Fan motor output rating：24VDC 1.4A

Temperature sensor　　OCE-TCPT11／OCE-TCPT12／OCE-TCPT13／OCE-TCPT14／OCE-TCPT15

Varied lineup to fit all types of BOXCOOL products

【Temperature sensing part dimensions】

[OCE-TCPT11] ø3.2×30mm／[OCE-TCPT12] ø3.2×50mm／[OCE-TCPT13] ø3.2×60mm／[OCE-TCPT14] ø3.2×80mm／[OCE-TCPT15] Ring terminal for M4

Do-it-youself kit OCE-KT3

Newly released! Ideal for studying the thermoelectric cooling system through assemblying the parts by yourself.

【Applications】

For people who hope to evaluate a thermoelectric cooler before adopting it, who hope to study the principle of Peltier module, or who hope to use it as an educational material at school

Water receptor

Water receptor for FF and LF

【Specifications】

[WP-15F] For OCE-F15F-D12　・　OCE-L15F-D12

[WP-40F] For OCE-F40F-D24　・　OCE-L40F-D24

[WP-80F] For OCE-F80F-D24　・　OCE-L80F-D24

[WP-120F] For OCE-F120F-D24

Switching power supply

AC/DC power converters for using the DC-powered BOXCOOLs with AC power supply

【Specifications】

Input voltage 85 to 264VAC ø1 (Rated input ： 100VAC／200VAC)

Wiring

【Item】

AC wiring, Thermal controller wiring, DC wiring
